Bluetooth Lighting Integrated Controller
1 Product Overview
1.1 Product model: FY-M101B
1.2 Product applications
DMX sub-controller is LED display data receiving equipment in lighting control system. The output adopts standard USITTDMX512/1990 general protocol and can be used for compatible DMX512(1990) signal protocol lighting control project.
1.3 Functional characteristics
1.3.1 biggest feature of Bluetooth lighting controller is to support mobile phone control, mobile phone address, a single set of controller has 8 port output, but also support multiple network port cascade synchronization.
1.3.2R、G、B independent brightness control.
1.3.3Gamma curve can be adjusted manually.
1.3.4 using gigabit technology, the maximum transmission distance of 100 meters, more than 100 meters can use optical fiber transmission.
1.3.5 software real-time detection system of all devices, intelligent identification system architecture, read the current state information of the device and generate status reports, monitor the operation of the project.
1.3.6 A、B port of the sub-controller can be used as input and output, and the signal can be input from the A、B port at the same time, so that when one of the signals is interrupted, it can quickly switch to another backup signal to ensure that the display is not affected.
1.3.7 with independent address line output, can be directly to the lamp address.
1.3.8 controller can upgrade firmware online, upgrade and maintenance more convenient.
