1. system adopts double loop backup, so that the system can switch seamlessly when one fault occurs, and ensure the stable operation of the display screen;
!
2. system can be compatible with multiple signal source input;
3. low power consumption, good heat dissipation;
4. modular design, modeling arbitrary;
5. structure stable, light weight, easy to install;
6. mute heat dissipation;
| Name of name | Ground screen | Step screen | Window screens | |
| Product model | IL-TC16 | IL-TC4 | IL-TC6 | IL-TC50 |
| Pixel spacing (mm) | 16 | 4 | 6 | 50 |
| pixel density (point/ m2) | 3906 | 62500 | 27777 | 400 |
| Pixel composition | 1R1G1B (SMD) | 2R2G2B (DIP) | ||
| :: Module size (mm) | 256*256 | 128*256 | 96*192 | / |
| :: Module resolution (row X column) | 16*16 | 32*64 | 16*32 | / |
| * Module size (mm) | 1024*1024 | / | / | 1600*1500 |
| :: Module resolution (row X column) | 64*64 | / | / | 32*30 |
| Weight (kg/m2) | w45 | w20 | w20 | W15 |
| :: Brightness (cd/m2) | m3500 | m1000 | m800 | m4000 |
| Color temperature | 3000K 〜9300K adjustable | |||
| Perspective | Level :160° | Level :140° | Level :140° | Level :120° |
| Vertical :°160 | Vertical :140° | Vertical :140° | Vertical :60° | |
| Brightness/ chrominance correction | Available | |||
| :: Peak power consumption (w/m2) | W380 | w650 | w400 | W260 |
| :: Average power consumption (w/m2) | W126 | w220 | w134 | W86 |
| Power supply requirements | AC380V +15%50 Hz(3 cabinet 5 wire system) | |||
| Drive mode | Constant current drive | |||
| Frame change frequency (Hz) | 60 | |||
| Refresh rate (Hz) | m1920 | |||
| Grayscale (bit) | m14 | |||
| Out of control | <1/10000(discrete) | |||
| Average failure-free time | m10000h | |||
| Typical lifetime values of luminous tubes | m100000h | |||
| Control distance | Super five types of network cable :<120 m, fiber: m10km | |||
| Signal compatibility | CVBS,YUV,RGB,DVI,HDSDI,HDMI | |||
| Working/storage temperature | Working temperature :10~+50°C; | Storage temperature :20 fences to +65 fences | ||
| Work/storage humidity | Working humidity :2 0% to 90% RH;; and | Storage humidity :10% to 95% RH | ||
