1. use SMD three-in-one technology, so that the LED screen in use with a greater perspective and better flatness;
2. high refresh rate, high gray level, watching the screen fine no flicker;
3. full color ,16 bit gray processing, super-level sense, display more delicate;
4. large angle of view 160° large angle of view, different angles of view, color and brightness can be consistent;
5. all-directional control scheme, not only support PC end, mobile phone end, LAN program release and system control, but also support remote several kinds of release and monitoring;
6. cluster management, can be different geographical location, a large number of circular screen system unified management and monitoring, to achieve multiple product splicing, linkage;
7. widely used, can be used to play corporate logo、 propaganda film, display clock, widely used in subway, shopping malls, cinemas, hotels, restaurants, showrooms, specialty stores, airports and other indoor, semi-outdoor occasions.
Product model | IL-TC1.85 |
Pixel spacing (mm) | 1.85 |
Diameter (m) | 0.71 |
Pixel composition | 1R1G1B (SMD) |
Screen Size (m2) | 0.396 |
Screen resolution (row X column) | 384*384 |
Flatness (mm) | W0.2 |
Weight (kg/m2) | 13 |
:: Brightness (cd/m2) | m1400 |
Color temperature | 3000K-9300K adjustable |
Perspective |
Level :160° Vertical :°160 |
:: Contrast | 3000:1 |
Brightness/ chrominance correction | Available |
:: Peak power consumption (w/m2) | W600 |
:: Average power consumption (w/m2) | W200 |
Power supply requirements | AC380V +15%50 Hz(3 cabinet 5 wire system) |
Drive mode | Constant current drive |
Frame change frequency (Hz) | 60 |
Refresh rate (Hz) | m3840 |
Grayscale (bit) | m16 |
Out of control | 15PPM |
Average failure-free time | m10000h |
Typical Value of Luminous Tube Life | m100000h |
Control distance | Super five types of network cable :<120 m, fiber: m10km |
Signal compatibility | CVBS,YUV,RGB,DVI,HDSDI,HDMI |
Working/storage temperature | Working temperature :10~+50°C; Storage temperature :20~+65 |
Work/storage humidity | Working humidity :20%90% RH; Storage humidity :10%95% RH |
Maintenance modality | Pure |
