1. High protection: military-grade protection technology, suitable for harsh outdoor environment;
Black screen high consistency: the best shell, mask design technology, so that the black screen can have high consistency, and after the spring, summer, autumn and winter still have a new screen flatness;
3, wide view angle: the whole screen over 120 degrees viewing angle, so that the audience can enjoy the best display at any angle;
4, high contrast: anti-glare mask design, and special all-black surface treatment technology to achieve high contrast;
High refresh rate: the stability of the picture is high, in the high-speed camera shooting state, the dynamic image will not appear black bar, the display effect is realistic, the picture is delicate and smooth;
High gray level: low brightness environment display screen level and bright sense is better than the same kind of display screen, the display screen is more delicate;
High consistency: use the most professional correction equipment to adjust the uniformity of color and brightness of the display screen to achieve perfect display effect.
Product model | IL-TC2.9 | IL-TC3.1 | IL-TC3.9 | IL-TC4.8 | IL-TC5.9 |
Pixel spacing (mm) | 2.976 | 3.125 | 3.91 | 4.81 | 5.952 |
pixel density (point/ m2) | 112896 | 102400 | 65536 | 43264 | 28224 |
Pixel composition | 1R1G1B (SMD) | ||||
Module size (mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
Module resolution (row X column) | 84*84 | 80*80 | 64*64 | 52*52 | 42*42 |
Module size (mm) | 500*500 | 500*500 | 500*500 | 500*500 | 500*500 |
Module resolution (row X column) | 168*168 | 160*160 | 128*128 | 104*104 | 84*84 |
Flatness (mm) | w0.5 | w0.5 | w0.5 | w0.5 | w0.5 |
Car Volume (kg/m2) | 40 | 40 | 40 | 40 | 40 |
:: Brightness (cd/m2) | m6000 | m6000 | m6000 | m6000 | m6000 |
Color temperature | 3000K-9300K adjustable | ||||
Perspective |
Level :140° Vertical :140° |
Level :140° Vertical :140° |
Level :140° Vertical :140° |
Level :140° Vertical :140° |
Level :140° Vertical :140° |
:: Contrast | 3000:1 | 3000:1 | 3000:1 | 3000:1 | 3000:1 |
Brightness/ chrominance correction | Available | ||||
:: Peak power consumption (w/m2) | W650 | W650 | W650 | w650 | w650 |
:: Average power consumption (w/m2) | W220 | W220 | W220 | w220 | w220 |
Power supply requirements | AC380V +15%50 Hz(3 cabinet 5 wire system) | ||||
Drive mode | Constant current drive | ||||
fr |
60 | ||||
Refresh rate (Hz) | m3840 | ||||
Grayscale (bit) | m14 | ||||
Out of control | <1/10000(discrete) | ||||
Average failure-free time | m10000h | ||||
Typical life value of luminous tube | m100000h | ||||
Control distance | Super five types of network cable :<120 m, fiber: m10km | ||||
Signal compatibility | CVBS,YUV,RGB,DVI,HDSDI,HDMI | ||||
Working/storage temperature | Working temperature :10~+50°C; Storage temperature :20~+65 | ||||
Work/storage humidity | Working humidity :20%90% RH; Storage humidity :10%95% RH | ||||
Maintenance modality | Former/post |
